Sjogren Manual Hand Wheel STYLE
ATS Pull Back
Collet Chucks
SJOGREN SPEED MANUAL COLLET CHUCKS
|
|
•
Manual collet chucks
• Adaptable to all spindle
configurations
• Utilizes standard 2J, 5C, 3J and 22J
collets
• Adaptable to Toolroom Lathes,
Engine Lathes, Rotary Tables, Vertical
Machining Centers, Gear Machines, Angle
Plates, and Drill Presses
• For stationary and turning operations
• Availiable in
• Hand Wheel actuation for easy
open and close
• CUSTOM SOLUTIONS AVAILABLE
• Pronounced SHOW-GRIN |
|
|
|
SYSTEMS BREAKDOWN
|
|
|
